| Hydraulic Breaker - DYB Series |
DONGYANG Silence Series will satisfy you with its economical efficiency.
DONGYANG silence series is an upgraded model with still maintaining the strong points of side and top type. |
| Description |
Unit |
DYB-210S |
DYB-300S |
DYB-400S |
DYB-500S |
| Operating Weight |
kg |
186 |
304 |
405 |
530 |
| lb |
409 |
625 |
891 |
1168 |
| Height (Incl.Tool) |
mm |
1363 |
1682 |
1684 |
2068 |
| inch |
53.7 |
66.2 |
66.3 |
81.4 |
| Operating Pressure |
bar |
110~130 |
140~160 |
140~160 |
120~150 |
| psi |
1595~1885 |
2031~2321 |
2031~2321 |
1707~2133 |
| Optimum Oil Flow |
§¤/min |
25~45 |
30~45 |
40~70 |
60~100 |
| gal/min |
6.6~11.9 |
7.9~11.9 |
10.8~18.4 |
15.8~26.4 |
| Impact rate |
bpm |
500~900 |
500~800 |
400~800 |
400~700 |
| Hose Diameter |
mm |
Ø12 |
Ø12 |
Ø12 |
Ø19 |
| inch |
1/2 |
1/2 |
1/2 |
3/4 |
Rod Diameter
& Weight |
mm |
60 |
68 |
75 |
85 |
| inch |
2.2 |
2.7 |
3.0 |
3.3 |
| kg |
14 |
18 |
26 |
40 |
| Applicable Carrier |
§© |
0.08~0.2 |
0.15~0.25 |
0.2~0.4 |
0.3~0.5 |
| ton |
3.0~5.5 |
4.0~7.0 |
6~9 |
7~12 |
| ft³ |
2.5~7 |
5.3~8.8 |
7.0~14.1 |
10.6~17.7 |
|
