Hydraulic Breaker - DYB Series |    Mini    |    Small    |    Medium    |    Large    | Silence Type Series Optimal Design To perform high impact energy with dependability. 1. Dampers for low noise & vibration. 2. Maximized availablity. 3. High productivity. Large Size Description Unit DYB-800S DYB-1200S DYB-1500S Operating Weight kg 1903 2495 3957 lb 4187 5410 8763 Height (Incl.Tool) mm 2822 3306 3838 inch 111.1 130.2 151.1 Operating Pressure bar 160~180 160~180 160~180 psi 2321~2611 2310~2610 2321~2611 Optimum Oil Flow ℓ/min 130~170 170~230 200~300 gal/min 34.3~44.9 45~62 52.8~79.3 Impact rate bpm 400~600 300~400 250~350 Hose Diameter mm Ø25 Ø32 Ø31 inch 1 11/4 11/4 Rod Diameter & Weight mm 140 155 175 inch 5.4 6.1 6.9 kg 133 180 247 Applicable Carrier ㎥ 0.7~0.9 0.9~1.1 1.4~2.0 ton 19~26 28~40 42~55 ft³ 25~32 27~34 42.4~60
